Ethernet PLC-5 Programmable Controllers 19
See the following table to proceed. If the PROC LED is not off, turn to the
next page for troubleshooting information.
To monitor your system as you configure and run it, check the controller’s
indicators:
If your controller is operating correctly, the:
• Ethernet STAT indicator remains solid green
• Ethernet Transmit indicators (100 M and 10 M) briefly light green when
transmitting packets
If the indicators do not indicate the above normal operation, refer to the
following table to troubleshoot the Ethernet indicators.
If Your Keyswitch is
in This Position Do This
PROGRAM Clear memory. The PROC LED should turn off.
The software is in Program mode.
REMOTE Clear memory. The PROC LED should turn off.
The software is in Remote Program mode.
RUN You see the message No access or privilege violation
because you cannot clear memory in Run mode. Change the
keyswitch position to Program or Remote and press Enter to
clear memory.
This Indicator Lights When
COMM You establish serial communication (CH 0)
BATT No battery is installed or the battery voltage is low
FORCE Forces are present in your ladder program
