20 Foundation Fieldbus Linking Device
Publication 1757-IN021E-EN-P - August 2009
Status Indicators
Linking Device Status Indicators
Indicator Status Description
H1 Off The linking device H1 channel is inactive.
Verify that the linking device is connected to the H1 network.
Flashing green The linking device H1 channel is active.
STATUS
(module) Off No power - Module does not have 24V DC power.
Verify that power is supplied to the module.
Flashing green Standby - Module not configured. (1)
Green Operational - Module operating correctly.
Flashing red Minor fault - A recoverable fault has been detected.
Verify that the configuration is correct and consistent.
Red Major fault - An unrecoverable fault has been detected.
Recycle power to the module. If this does not clear the fault,
replace the module.
WDOG
(watchdog) Off Normal operation.
Flashing red Software fault.
Contact Rockwell Automation Technical Support.
BATT
(battery) Off Normal operation.
Flashing red Jumper is missing (or not seated on the two rightmost pins), or
the battery is low or dead.
(2)
NS
(network
status) Off Not powered, no IP address.
Verify that power is supplied or assign an IP address.
Flashing green No connections. (1)
Verify that the linking device is connected to the fieldbus
network.
Green CIP connections.
Flashing red Connection timeout.
Verify that the linking device is connected to the Ethernet
network.
Flashing red
and green Self test.
