Appendix
A
Publication 1747-10.4
Specifications
The table below lists SLC 500 system test specifications.
Description Specification Industry Standard
Temperature
Operating: 0
°
C to +60
°
C (32
°
F to 140
°
F) Not Applicable
Temperature
Storage: –40
°
C to +85
°
C (–40
°
F to 185
°
F) Not Applicable
Humidity 5 to 95% without condensation Not Applicable
ibration
Operating: 1.0G at 5 to 2000 Hz Not Applicable
Vibration
Non-operating: 2.5Gs at 5 to 2000 Hz Not Applicable
Operating: 30.0Gs (3 pulses, 11 ms) Not Applicable
Shock Operating: 10.0Gs (3 pulses, 11 ms) Not Applicable
Non-operating: 50.0Gs (3 pulses, 11 ms) Not Applicable
Free Fall (drop test)
Portable, 2.268 kg (5 lbs) or less at 0.762m
(30 in.) (six drops)
Not Applicable
Free Fall (drop test)
Portable, 2.268 kg (5 lbs) or more at 0.1016m
(4 in.) (three flat drops)
Not Applicable
Showering Arc: 1.5 kV NEMA ICS 2-230/NEMA ICS 3-304
Surge Withstand Capability: 3 kV IEEE Std. 472-1974/ANSI C37.90/90A-1974
Electromagnetic Compatibility
Fast Transient Burst (impulse): 2 kV for 1746
power supplies, 1kV for 1746 I/O and
communication lines over 10m (32.84 ft), 5 ns
rise time
Internal Rockwell Automation standard
➀
Electrostatic Discharge (ESD): 15 kV,
100 pF/1.5k ohm model
Internal Rockwell Automation standard
➀
Radiated Electromagnetic Susceptibility: 5W
walkie-talkie at 464.5 MHz and 153.05 MHz
Internal Rockwell Automation standard
➀
Dielectric Withstand: 1500V ac UL 508, CSA C22.2 No. 142
Safety
Isolation between Communication Circuits:
500V dc
Not Applicable
Safety
Isolation between Backplane and I/Os: 1500V
ac
Not Applicable
Flammability and Electrical Ignition: UL94V-0 Not Applicable
Certification
UL listed/CSA approved
Class 1, Groups A, B, C or D, Division 2
CE compliant for all applicable directives
Not Applicable
➀
Internal Rockwell Automation standards are based on Rockwell Automation’s extensive experience in industrial controls.
It is also based partly on industry and/or military specifications.
System Test General
Specifications
