4–5 Communicating on the Ethernet Network
Publication 1747-10.4
SLC 5/05 Channel 1 (Ethernet port)
MSG Control Block with Logical ASCII Addressing
valid for PLC-5 typed read or write only
WORD 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
0 EN ST DN ER CO EW NR TO Error Code
1 Reserved (Target Node Not Used)
2 Number of Elements
3 Not Used
4 File Type (based on local source or destination address)
5 Not Used
6 Not Used
7 Reserved (Internal Messaging Bits) WQ
8 Message Timer Preset
9 Message Timer Scaled Zero
10 Message Timer Accumulator
11 Data Length in Bytes
12 AO=1 Reserved (Internal Messaging Bits) Reserved
13 Reserved
14 Logical ASCII Address String Length including NULL Termination Character (bytes)
15 First Byte of ASCII Address String Second Byte of ASCII Address String
16 Third Byte of ASCII Address String
…
… …
… …
55 Eighty-First Byte of ASCII Address String NULL Byte of Longest ASCII Address String
56 First Byte of IP Address String
➀
Second Byte of IP Address String
57 Third Byte of IP Address String
…
… …
… …
76 Forty-First Byte of IP Address String NULL Byte of Longest IP Address String
77 Reserved Reserved (Ethernet Message Type); must be 0
78–92 Reserved for Future Use
➀
The IP Address string format is up to 42 ASCII characters including a terminating NULL character. The first byte in the array is the
left-most character in the string as written. For example: If the IP Address is 423.156.78.012, the first byte is the ASCII character “4”. If
the MSG destination is an INTERCHANGE client on a host computer, the destination is specified as “client” and stored as a NULL
terminated string.
