Par # Parameter Name Factory Default Programmed Value Par # Parameter Name Factory Default Programmed Value
1 Output Voltage Read Only 292 Load Loss Time 0 Sec
2 % Output Curr Read Only 293 PI Max Error Maximum Freq Forward
3 % Output Power Read Only 294 DSP Comm Errors
4 Last Fault Read Only 295 Max PWM Depth
5 Freq Select 1 Adapter 1 296 Tuned Flux Amps
6 Freq Select 2 Preset 1 297 Tuned IR Drop
7 Accel Time 1 10.0 Sec 298 Run Time Lower
8 Decel Time 1 10.0 Sec 299 Run Time Upper
9 Control Select Sens Vector 300 Spare
10 Stop Select 1 Coast 301 DSP Code Rev
11 Bus Limit En Disabled 302 Main Boot Rev
12 DC Hold Time 0.0 Sec 303 Current Lmt En Enabled
13 DC Hold Level 0% 304 Traverse Dec 0.00 Sec
14 Run On Power Up Disabled 305 Traverse Mask 01111111
15 Reset/Run Time 1.0 Sec 306 Traverse Owner Read Only
16 Minimum Freq 0 Hz 307 Sync Time 0.0 Sec
17 Base Frequency 60 Hz 308 Sync Mask 01111111
18 Base Voltage Drive Rated Volts 309 Sync Owner Read Only
19 Maximum Freq 60 Hz 310 Sync Loss Sel Disabled
20 Maximum Voltage Drive Rated Volts 311 Sync Loss Gain 0
21 Spare 312 Sync Loss Time 5 Sec
22 MOP Increment 1.1 Hz/Sec 313 Sync Loss Comp 0 Volts
23 Output Power Read Only 314 Braking Chopper Disabled
24 Jog Frequency 10.0 Hz 315 Alt Type 2 Cmd Disabled
25 Anlg Out 0 Sel Frequency 316 Application Sts
26 Stop Mode Used Coast 317 Run/Accel Volts 100%
27 Preset Freq 1 0.0 Hz 318 Max Overflux
28 Preset Freq 2 0.0 Hz 319 Speed Brake En Disabled
29 Preset Freq 3 0.0 Hz 320 Line Loss Volts 59/117/146 Volts
30 Accel Time 2 10.0 Sec 321 Loss Recover 29/59/73 Volts
31 Decel Time 2 10.0 Sec 322 Ride Thru Volts 29/59/73 Volts
32 Skip Freq 1 400 Hz 323 Min Bus Volts 194/388/485 Volts
33 Skip Freq 2 400 Hz 324 Stability Gain 0
34 Skip Freq 3 400 Hz 325 Max Bus Volts 358/716/895 Volts
35 Skip Freq Band 0 Hz 326 Remote CR Output xxxx0000
36 Current Limit 150% 327 At Time 0.00 Sec
37 Overload Mode No Derate 328 Max Enc Counts 0
38 Overload Amps 115% of Drive Rating 329 Bidir In Offset 270
39 Flt Clear Mode Enabled 330 Phase Loss Mode Disabled
40 Line Loss Fault Disabled 331 Phase Loss Level 9.0/18.0/22.5 Volts
41 Motor Type Induction 332 Precharge Fault Disabled
42 Slip @ F.L.A. 1.0 Hz
43 Dwell Frequency 0.0 Hz
44 Dwell Time 0 Sec
45 PWM Frequency 2 KHz
46 Encoder PPR 1024 PPR
47 Language English
48 Start Boost 0 Volts
49 Break Frequency 25% of [Maximum Freq]
50 Break Voltage 25% of Drive Rated Voltage
51 Clear Fault Ready
52 Stop Select 2 Coast
53 DC Bus Voltage Read Only
54 Output Current Read Only
55 Input Status
56 S Curve Time 0.0 Sec
57 S Curve Enable Disabled
58 Common Bus Disabled
