Rockwell Automation 1336F Plus II Parameters - Manual (Page 13)

1336 PLUSII Parameter Record
Machine #
Date programmed
Drive Serial #
Par # Parameter Name Minimum Value Maximum Value Factory Default Programmed Value
206 Alarm Mask 1 Bus Charging 1111111111111111
Hardware Current Limit
Motoring Current Limit
Regenerating Current Limit
Regenerating Voltage Limit
Line Loss In Progress
Mtr Overload
Motor Stalled
Ground Warning
Auxilliary Input
Heatsink Temp
Sync Loss
Phase Loss
4-20 mA Loss
Motor OL Trip
Auto Reset
207 Fault Data 1 255 Read and Write
208 Time Data 1
209 Time Data 3
210 Time Data 5
211 Time Data 7
212 DC Bus Memory
Read Only
213 PI Config Inv Error - Changes sign of PI Error 00000000
Reset Int - Holds K1 at zero
Zero Clamp - Prevents bidirectional operation
Sqrt Fdbk-Uses sq. root of PI feedback value
Set Output
Preload Int
PI Enable
Spare
214 PI Status Enabled Read Only
Spare
Spare
Spare
Spare
Spare
Spare
Spare
215 PI Ref Select Use Last Preset 1
Analog In 0
Analog In 1
Analog In 2
Pulse Ref
MOP
Adapter 1
Adapter 2
Adapter 3
Adapter 4
Adapter 5
Adapter 6
Preset 1
Preset 2
Preset 3
Preset 4
Preset 5
Preset 6
Preset 7
Encoder
216 PI Fdbk Select Use Last Analog In 1
Analog In 0
Analog In 1
Analog In 2
Pulse Ref
MOP
Adapter 1
Adapter 2
Adapter 3
Adapter 4
Adapter 5
Adapter 6
Preset 1
Preset 2
Preset 3
Preset 4
Preset 5
Preset 6
Preset 7
Encoder
217 PI Reference -400.00 Hz 400.00 Hz Read Only
218 PI Feedback -400.00 Hz 400.00 Hz Read Only
219 PI Error -400.00 Hz 400.00 Hz Read Only
220 PI Output -400.00 Hz 400.00 Hz Read Only
221 KI Process 0 1024 128
222 KP Process 0 1024 256
223 PI Neg Limit -400.00 Hz 400.00 Hz -8.33% of [Maximum Freq]
224 PI Pos Limit -400.00 Hz 400.00 Hz +8.33% of [Maximum Freq]
225 PI Preload -8.33% of [Maximum Freq] +8.33% of [Maximum Freq] 0.00 Hz
226 Shear Pin Fault Disabled Disabled
Enabled
Not Accel
227 Adaptive I Lim Disabled Enabled
Enabled
228 LLoss Restart Speed Search Track Volts
Use Encoder
Track Volts
Last Speed
229 Freq Ref SqRoot Disabled Disabled
Enabled
230 Save MOP Ref Disabled Disabled
Enabled
