1336 PLUSII Parameter Record
Machine #
Date programmed
Drive Serial #
Par # Parameter Name Minimum Value Maximum Value Factory Default Programmed Value
247 TB3 Term 28 Sel Unused Speed Sel 1
Jog
Speed Sel 1
Speed Sel 2
Speed Sel 3
1st Accel
2nd Accel
2 Acc/1 Acc
1st Decel
2nd Decel
2 Dec/1 Dec
Clear Fault
Aux Fault
Local Ctrl
Traverse
Sync
PI Enable
PI Reset
Dig Pot Up
Dig Pot Dn
Stop Type
Forward
Reverse
Rev/For
Run Reverse
CB Precharge
248 Anlg In 2 Lo -300.0% +300.0% 0.0%
249 Anlg In 2 Hi -300.0% +300.0% 100.0%
250 Anlg Signal Loss Input 0 Signal Loss for Pot - 1=Yes, 0=No
Input 1 Signal Loss for Pot - 1=Yes, 0=No
Input 2 Signal Loss for Pot - 1=Yes, 0=No
Input 0 Signal Loss for 4-20mA/2-10V - 1=Yes, 0=No
Input 1 Signal Loss for 4-20mA/2-10V - 1=Yes, 0=No
Input 2 Signal Loss for 4-20mA/2-10V - 1=Yes, 0=No
Not Used
Not Used
251 Cntrl Board Rev Read Only
252 Slot A Option Standard Standard
LA1
LA2
LA3
LA4
LA5
LA6
LA7
Undefined
253 Slot B Option Standard Standard
LA1
LA2
LA3
LA4
LA5
LA6
LA7
Undefined
254 Pulse Freq -400.00 Hz +400.00 Hz Read Only
255 Slip Adder -8.33% of [Base Frequency] +8.33% of [Base Frequency] Read Only
256 Line Loss Mode LoBus>Off LoBus>Off
Input>Off
LoBus>Decel
Input>Decel
257 Spare
258 DSP Spare A
259 DSP Spare B
260 DSP Spare C
261 DSP Spare D
262
DSP Spare E
263 DSP Spare F
264 Pulse In Scale 1 4096 64 PPR
265 DSP Comm Fault
266 Min Comm Slots
267 Dig At Temp
0 255 o C 120 o C
268 Motor Therm Flt Disabled Enabled
Enabled
269 Drive Alarm 2 Motor Therm
Load Loss
Encoder Loss
Enc Cnt Set
Enc Cnt Max
Voltage Check
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
