1336 PLUSII Parameter Record
Machine #
Date programmed
Drive Serial #
Par # Parameter Name Minimum Value Maximum Value Factory Default Programmed Value
175 CR3 Out Select Fault Fault
Alarm
Running
At Speed
At Freq
At Current
At Torque
Current Lmt
Mtr Overload
Line Loss
Drive Power
Drive Ready
Forward Run
Reverse Run
Braking
Economize
Auto Reset
At Temp
PI Max Error
Remote
176 CR4 Out Select Fault Alarm
Alarm
Running
At Speed
At Freq
At Current
At Torque
Current Lmt
Mtr Overload
Line Loss
Drive Power
Drive Ready
Forward Run
Reverse Run
Braking
Economize
Auto Reset
At Temp
PI Max Error
Remote
177 Motor NP RPM 60 RPM 24000 RPM 1750 RPM
178 Motor NP Hertz 1 Hz 400 Hz 60 Hz
179 Local Owner 0 Read Only
1
180 Process 2 Par 54
181 Process 2 Scale -327.68 +327.67 +1.00
182 Process 2 Txt 1 Amps
183 Process 2 Txt 2 Amps
184 Process 2 Txt 3 Amps
185 Process 2 Txt 4 Amps
186 Process 2 Txt 5 Amps
187 Process 2 Txt 6 Amps
188 Process 2 Txt 7 Amps
189 Process 2 Txt 8 Amps
190 Motor NP Volts 0 Volts 2 x Drive Rated Volts Drive Rated Volts
191 Motor NP Amps 0 Amps 2 x Drive Rated Amps Drive Rated Amps
192 Flux Amps Ref 0.0 Amps 75.0% of Drive VT Rated Amps 0.0 Amps
193 KP Amps 25 400 100
194 IR Drop Volts 0.0 Volts 25% of Drive Rated Volts Based on Drive Size & Type
195 Slip Comp Gain 1 40 1
196 KP Volts
197 Prod/Cnsu Error
198 Rated VT Amps
Read Only
199 Rated VT kW Read Only
200 Flux Up Time 0.0 Sec 5.0 Sec 0.0 Sec
201 Motor OL Fault Disabled Enabled
Enabled
202 Motor OL Count 0% 200% Read Only
203 VT Scaling Disabled Disabled
Enabled
204 Ground Warning Disabled Disabled
Enabled
205 Latched Alarms 1 Bus Charging
Hardware Current Limit
Motoring Current Limit
Regenerating Current Limit
Regenerating Voltage Limit
Line Loss in Progress
Mtr Overload
Motor Stalled
Ground Warning
Auxillary Input
Heatsink Temp
Sync Loss
Phase Loss
4-20 mA Loss
Motor OL Trip
Auto Reset
