Wiring
Chapter 6
6-15
Terminal Block TB1 - L1, L2, L3
B150ĆB200 & C150ĆC200
Input AC line Terminals L1, L2, L3 (
∅
A,
∅
B,
∅
C) are not
∅
sensitive.
Power Wiring (cont.)
For drives rated B150-B200, nominal input voltage is 380/415/460V AC
±
10%, 3
∅
, 50/60 Hz.
For drives rated C150-C200, nominal input voltage is 500 or 575V AC
±
10%, 3
∅
, 50/60 Hz.
Branch disconnect and short circuit protection is not part of the standard
1336 and must be supplied by the user. Drive input fuses are required to
provide component protection against malfunction of electronic circuits.
Terminal Block TB1 -
B150ĆB200 Power Wiring
+DC and –DC +DC and –DC M1-M3 M1-M3
Power Drive Terminal Block Terminal Block Terminal Block Terminal Block
Rating Output Wire Maximum Maximum Maximum Maximum
Code Current Group ❶ Wire Size ❷ Torque ❸ Wire Size ❹ Torque ❺
B150 218 Amps 2 350 MCM 275 In-lbs 500 MCM 375 In-lbs
B200 290 Amps 2 350 MCM 275 In-lbs 500 MCM 375 In-lbs
❶ Wire group number chart, page 6-3.
❷ 185 mm
2 .
❸ 31.08 N-m.
❹ 240 mm
2 .
❺ 42.38 N-m.
Select from the following drive input fuses when using branch circuit protection.
Drive Rating B150 Fuse Size 300A Fuse Type A4J, JJS or Equivalent
Drive Rating B200 Fuse Size 400A Fuse Type A4J, JJS or Equivalent
Terminal Block TB1 -
C150ĆC200 Power Wiring
+DC and –DC +DC and –DC M1-M3 M1-M3
Power Drive Terminal Block Terminal Block Terminal Block Terminal Block
Rating Output Wire Maximum Maximum Maximum Maximum
Code Current Group ❶ Wire Size ❷ Torque ❸ Wire Size ❹ Torque ❺
C150 158 Amps 2 350 MCM 275 In-lbs 500 MCM 375 In-lbs
C200 210 Amps 2 350 MCM 275 In-lbs 500 MCM 375 In-lbs
❶ Wire group number chart, page 6-3.
❷ 185 mm
2 .
❸ 31.08 N-m.
❹ 240 mm
2 .
❺ 42.38 N-m.
Select from the following drive input fuses when using branch circuit protection.
Drive Rating C150 Fuse Size 175A Fuse Type A4J, JJS or Equivalent
Drive Rating C200 Fuse Size 250A Fuse Type A4J, JJS or Equivalent
