Wiring
Chapter 6
6-7
Terminal Block TB1 -
B003ĆB030 Power Wiring
Power Drive Maximum
Rating Output Wire Wire Maximum
Code Current Group ❶ Size ❷ Torque ❸
B003 6.0 Amps 2 6 AWG 20 In-lbs
B005 9.6 Amps 2 6 AWG 20 In-lbs
B007 13.0 Amps 2 6 AWG 20 In-lbs
B010 17.0 Amps 2 6 AWG 20 In-lbs
B015 25.0 Amps 2 6 AWG 20 In-lbs
B020 33.0 Amps 2 6 AWG 20 In-lbs
B025 41.0 Amps 2 6 AWG 20 In-lbs
B030 48.0 Amps 2 6 AWG 20 In-lbs
❶ Wire group number chart, page 6-3.
❷
16 mm 2 .
❸ 2.26 N-m.
Select from the following drive input fuses.
Drive Rating B003 Fuse Size 10A Fuse Type KTK-R, JJS or Equivalent
Drive Rating B005 Fuse Size 15A Fuse Type KTK-R, JJS or Equivalent
Drive Rating B007 Fuse Size 20A Fuse Type KTK-R, JJS or Equivalent
Drive Rating B010 Fuse Size 25A Fuse Type KTK-R, JJS or Equivalent
Drive Rating B015 Fuse Size 35A Fuse Type A4J, JJS or Equivalent
Drive Rating B020 Fuse Size 45A Fuse Type A4J, JJS or Equivalent
Drive Rating B025 Fuse Size 60A Fuse Type A4J, JJS or Equivalent
Drive Rating B030 Fuse Size 70A Fuse Type A4J, JJS or Equivalent
Terminal Block TB1 -
C003ĆC030 Power Wiring
Power Drive Maximum
Rating Output Wire Wire Maximum
Code Current Group ❶ Size ❷ Torqu e ❸
C003 4.3 Amps 2 6 AWG 20 In-lbs
C005 6.7 Amps 2 6 AWG 20 In-lbs
C007 9.9 Amps 2 6 AWG 20 In-lbs
C010 12.1 Amps 2 6 AWG 20 In-lbs
C015 19.0 Amps 2 6 AWG 20 In-lbs
C020 24.0 Amps 2 6 AWG 20 In-lbs
C025 30.0 Amps 2 6 AWG 20 In-lbs
C030 35.0 Amps 2 6 AWG 20 In-lbs
❶ Wire group number chart, page 6-3.
❷ 16 mm
2 .
❸ 2.26 N-m.
Select from the following drive input fuses.
Drive Rating C003 Fuse Size 6A Fuse Type KTK-R, JJS or Equivalent
Drive Rating C005 Fuse Size 6A Fuse Type KTK-R, JJS or Equivalent
Drive Rating C007 Fuse Size 10A Fuse Type KTK-R, JJS or Equivalent
Drive Rating C010 Fuse Size 15A Fuse Type KTK-R, JJS or Equivalent
Drive Rating C015 Fuse Size 20A Fuse Type A4J, JJS or Equivalent
Drive Rating C020 Fuse Size 25A Fuse Type A4J, JJS or Equivalent
Drive Rating C025 Fuse Size 30A Fuse Type A4J, JJS or Equivalent
Drive Rating C030 Fuse Size 35A Fuse Type A4J, JJS or Equivalent
