Logic Interface Options
Appendix A
A-17
1336ĆMODĆL3 115V AC Terminals 21, 25, 29
Logic Interface Board
Interface Common
Terminals 21, 25 and 29 are used to terminate both minus or interface
common signals to TB3. Terminals 21, 25 and 29 are also used to terminate
any shields for cables connected to TB3. For the 1336-MOD-L3 115V AC
Logic Interface Board, Terminals 21, 25 and 29 are isolated from drive
signal common, chassis ground, and earth ground.
Terminal 22 and Interface Common
Jog
True = Jog
False = Interrupt Jog and Allow Other Functions
This input will jog the drive if it is not running and interlocks permit. As
long as interlocks permit and the jog command remains True, the drive will
continue to run at the programmed jog frequency.
Terminal 23 and Interface Common
Reverse
Maintained True = Reverse
Maintained False = Forward
Parameter 22 enables the direction of drive rotation to be controlled by an
input at Terminal 23. A maintained False will select the forward direction,
a maintained true the reverse direction.
Terminal 24 and Interface Common
SW1
True = SW1 Function Selected
False = SW1 Function Not Selected
Parameters 26-31 and 72-76 define the SW1 function.
Terminal 26 and Interface Common
SW2
True = SW2 Function Selected
False = SW2 Function Not Selected
Parameters 26-31 and 72-76 define the SW2 function.
