Appendix
E
Publication 1403-5.1
Technical Specifications
Product Approvals
UL 508 Component Recognized File E96956 and
CSA C22.2 approval for Industrial Control Equipment.
Compliance to European Union Directives
If this product has the CE mark it is approved for
installation within the European Union and EEA regions.
It has been designed and tested to meet the following
directives.
EMC Directive
This product is tested to meet Council Directive
89/336/EEC Electromagnetic Compatibility (EMC) and
the following standards, in whole or in part, documented
in a technical construction file:
•
EN 50081-2 – Generic Emission Standard, Part 2 –
Industrial Environment
•
EN 50082-2 – Generic Immunity Standard, Part 2 –
Industrial Environment
This product is intended for use in an industrial
environment.
Low Voltage Directive
This product is tested to meet Council Directive
73/23/EEC Low Voltage, by applying the safety
requirements of IEC 1010-1.
This equipment is classified as open equipment and must
be installed (mounted) in an enclosure during operation
as a means of providing safety protection.
Screw Torque and Wire Size
Position Ratings
Mounting Screw Tightening
Torque
0.9 to 1.1 Nm (8 to 10 lb-in.)
Communications Connector 0.6 to 0.8 Nm (8 to 10 lb-in.)
Terminal Screw Tightening
Torque
0.2 to 2.5 mm 2 (24-12 AWG),
stranded or solid wire, Cu wire
only.
Terminal Block/Wire Insulation
Temperature Index
75
°
C maximum
Environmental Specifications
Operating Temperature –40
°
C to +60
°
C
Storage Temperature –40
°
C to +85
°
C
Humidity
5 to 95 percent,
non-condensing
Vibration
Operational: 0.006 in. DA/1.0 G
Sine, 10 to 500 Hz, 3
orthogonal axes.
Vibration
Non-operational: 0.015 in.
DA/2.5 G Sine, 10 to 500 Hz, 3
orthogonal axes.
Shock
Operational: 15 G, Half Sine,
11 ms duration, 3 orthogonal
axes, 3 (+) and 3 (–)
pulses/axes, 18 pulses total.
Shock
Non-operational: 30 G, Half
Sine, 11 ms duration, 3
orthogonal axes, 3 (+) and 3 (–)
pulses/axes, 18 pulses total.
