B–17 Smart Communication Card Data Tables
Publication 1403-5.1
Table B.16 Available Min/Max Log Parameters (Identifiers for parameter 12.4)
Parameter Number Parameter Description
1 Phase 1 Current
2 Phase 2 Current
3 Phase 3 Current
4 Phase 4 Current
5 Average Current
6 Positive Sequence Current
7 Negative Sequence Current
8 Current Unbalance
9 Phase 1 L–L Voltage
10 Phase 2 L–L Voltage
11 Phase 3 L–L Voltage
12 Auxiliary Voltage
13 Average L–L Voltage
14 Positive Sequence Voltage
15 Negative Sequence Voltage
16 Voltage Unbalance
17 Phase 1 L–N Voltage
18 Phase 2 L–N Voltage
19 Phase 3 L–N Voltage
20 Average L–N Voltage
21 Frequency
22 Phase 1 Real Power
23 Phase 2 Real Power
24 Phase 3 Real Power
25 Total Real Power
26 Phase 1 Reactive Power
27 Phase 2 Reactive Power
28 Phase 3 Reactive Power
29 Total Reactive Power
30 Phase 1 Apparent Power
31 Phase 2 Apparent Power
32 Phase 3 Apparent Power
33 Total Apparent Power
34 Phase 1 True Power Factor
35 Phase 2 True Power Factor
36 Phase 3 True Power Factor
37 Total True Power Factor
38 Phase 1 Displacement Power Factor
39 Phase 2 Displacement Power Factor
40 Phase 3 Displacement Power Factor
41 Total Displacement Power Factor
42 Phase 1 Distortion Power Factor
Parameter Number Parameter Description
43 Phase 2 Distortion Power Factor
44 Phase 3 Distortion Power Factor
45 Total Distortion Power Factor
46 Current Demand
47 Real Power Demand
48 Reactive Power Demand
49 Apparent Power Demand
50 Phase 1 Voltage IEEE THD
51 Phase 1 Voltage IEC THD
52 Phase 1 Voltage TIF ①
53 Phase 1 Voltage Crest Factor ①
54 Phase 1 Voltage K-factor ①
55 Phase 1 Current IEEE THD
56 Phase 1 Current IEC THD
57 Phase 1 Current TIF ①
58 Phase 1 Current Crest Factor ①
59 Phase 1 Current K-factor ①
60 Phase 2 Voltage IEEE THD
61 Phase 2 Voltage IEC THD
62 Phase 2 Voltage TIF ①
63 Phase 2 Voltage Crest Factor ①
64 Phase 2 Voltage K-factor ①
65 Phase 2 Current IEEE THD
66 Phase 2 Current IEC THD
67 Phase 2 Current TIF ①
68 Phase 2 Current Crest Factor ①
69 Phase 2 Current K-factor ①
70 Phase 3 Voltage IEEE THD
71 Phase 3 Voltage IEC THD
72 Phase 3 Voltage TIF ①
73 Phase 3 Voltage Crest Factor ①
74 Phase 3 Voltage K-factor ①
75 Phase 3 Current IEEE THD
76 Phase 3 Current IEC THD
77 Phase 3 Current TIF ①
78 Phase 3 Current Crest Factor ①
79 Phase 3 Current K-factor ①
80 Phase 4 Current IEEE THD
81 Phase 4 Current IEC THD
82 Phase 4 Current TIF ①
83 Phase 4 Current Crest Factor ①
84 Phase 4 Current K-factor ①
➀ Not available on 1403-LM.
