Adapter specifications – Rockwell Automation 1395 Discrete Adapter, Rev 3.XX-8.XX User Manual
Page 6

Chapter 1
Introduction
1-2
Adapter Specifications
A listing of board specifications and features is provided in Table 1.A. Any
specifications pertaining directly to procedures detailed in this manual, will
be stated where necessary in the manual.
Table 1.A
Discrete Board Specifications
Type
Digital Inputs
Discrete Outputs
Analog Inputs
Power Supply
Analog Outputs
Firmware Version
Use
24V DC or 120V AC, 10mA. NOTE: A separate board and part number is
used for each voltage rating.
Dry relay contacts rated at 0.6 Amps at 125V AC or 2.0 Amps
at 30V DC.
0 to (
±
) 10V DC, Differential
Input Impedance - 20K ohms
10 to +10V DC ,10 mA maximum
Output Impedance - 200 ohms
+ 10V DC, 4 mA maximum
- 10V DC, 4 mA maximum
3.xx
