Chapter 8
Parameter Table
8-3
Function – Indicates the related control function for the parameter.
Port – Indicates port that parameter is associated with.
Table 8.A
Parameter Table
Param Number
DEC
HEX NAME UNITS INIT MIN MAX EE FUNCTION PORT
300 12CH B>Digital Input Configuration Port B
301 12DH B>Analog In 1 Configuration Port B
302 12EH B>Analog In 2 Configuration Port B
303 12FH B>Analog In 3 Configuration Port B
304 130H B>Analog In 4 Configuration Port B
305 131H Not Used Configuration Port B
to to
349 150H
350 15EH B>Digital Output Configuration Port B
351 15FH B>Analog Out 1 Configuration Port B
352 160H B>Analog Out 2 Configuration Port B
353 161H B>Analog Out 3 Configuration Port B
355 162H B>Analog Out 4 Configuration Port B
355 163H Not Used Configuration Port B
to to
359 167H Not Used Configuration Port B
400 190H A>Digital Input Configuration Port A
401 191H A>Analog In 1 Configuration Port A
402 192H A>Analog In 2 Configuration Port A
403 193H A>Analog In 3 Configuration Port A
404 194H A>Analog In 4 Configuration Port A
405 195H Not Used Configuration Port A
406 196H Not Used Configuration Port A
to to
409 199H Not Used Configuration Port A
450 1C2H A>Digital Output Configuration Port A
451 1C3H A>Analog Out1 Configuration Port A
452 1C4H A>Analog Out2 Configuration Port A
453 1C5H A>Analog Out3 Configuration Port A
454 1C6H A>Analog Out4 Configuration Port A
455 1C7H Not Used Configuration Port A
to to
459 1CBH Not Used Configuration Port A
500 1F4H B>ADC Scale 1 VLT 1 -16 16 EE SetĆUp Port B
