Bulletin 1606 Switched Mode Power Supplies
18. EMC
The unit is suitable for applications in industrial environments as well as in residencial, commercial and light industry
environment without any restrictions. The CE Mark indicates conformance with EMC guideline 89/336/EC, 93/68/EC and
2004/108/EC and the low-voltage directive (LVD) 73/23/EC, 93/68/EC and 2006/95/EC.
A detailed EMC report is avalaible upon request.
EMC Immunity
EN 61000-6-1, EN 61000-6-2 Generic standards
Electrostatic discharge
EN 61000-4-2
Contact discharge
Air discharge
8kV
15kV
Criterion A*)
Criterion A*)
Electromagnetic RF field
EN 61000-4-3
80MHz-2.7GHz
10V/m
Criterion A
Fast transients (Burst)
EN 61000-4-4
Out- and Input lines
Signal lines **)
2kV
2kV
Criterion A
Criterion A
Surge voltage
EN 61000-4-5
+ -
500V
500V
Criterion A
Criterion A
+ - housing
500V
Criterion A
Conducted disturbance
EN 61000-4-6
0.15-80MHz
10V
Criterion A
*) DIN rail earthed
**) Tested with coupling clamp.
EMC Emission
EN 61000-6-3 and EN 61000-6-4 Generic standards
Conducted emission
EN 55022
Input lines
Class B*)
Class B*)
Radiated emission
EN 55011, EN 55022
Class B
This device complies with FCC Part 15 rules.
Operation is subjected to following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired operation.
*)
Informative measurement with voltage probe
Switching frequency
The DC-UPS has three converters with three different switching frequencies included.
Switching
frequency
of
boost
converter
100kHz
Constant
frequency
Switching frequency of electronic output current limitation
78kHz
Constant frequency
Switching frequency of battery charger
19.5kHz
Constant frequency
Output
Input + -
EN 55022
Output lines
