Step 1: remove drive assembly – Rockwell Automation 21G PowerFlex 755 Transition Section and Splicing Kit User Manual
Page 6

6
Rockwell Automation Publication 750-IN027C-EN-P - November 2013
PowerFlex 755 Transition Section and Splicing Kit for Floor-mount Drives and CENTERLINE 2100 Motor Control Centers
Joining Drive, Transition
Section, and MCC
Physical restrictions at your installation may not allow the following sequence to
be followed exactly as stated.
Step 1: Remove Drive Assembly
The PowerFlex 755 drive assembly must be removed to access side panels and
horizontal bus bars.
For detailed information on removing and handling the PowerFlex 755 drive
assembly, refer to the PowerFlex 750-Series AC Drives Installation Instructions,
publication
750-IN001
. Special equipment is required.
Step 2: Remove Plug-in Units, Support Pans, and Access Covers
All plug-in units and support pans must be removed to access side panels and
horizontal bus bars.
To complete plug-in unit removal refer to Installing Units with Horizontal
Operating Handles, publication
2100-IN060
, and Installing Units with Vertical
Operating Handles, publication
2100-IN014
.
If you’re installing a left-mount kit, see
page 7
.
If you’re installing a right-mount kit, see
page 14
.
ATTENTION: This drive has a high center of gravity and a tip-over hazard exists.
To guard against death, serious personal injury, and/or equipment damage, do
not subject the drive to high rates of acceleration or deceleration while
transporting. Do not push or pull above the points indicated on the drive.
ATTENTION: Plug-in MCC units may be heavy or awkward to handle. Use an
assistant or a platform lift device if necessary to help you handle the unit
ATTENTION: MCCs are top and front heavy. To avoid personal injury or
structural damage, never attempt to lift or move the MCC by any means other
than the methods outlined in Receiving and Storing Motor Control Centers,
publication
2100-IN040
.
IMPORTANT
After completing these instructions, refer to the publications listed on this page and
under
Additional Resources on page 2
for detailed information on reinstalling
equipment and components.
