Muting Controller Box Installation and Operating Instructions
25
R
Original instructions
Technical Data
General data
Temperature range Environment temp.: 0…+55°C (32…131°F); Stock temp.: -25…+70°C (-13…158°F)
Enclosure rating according EN 60529 IP65
Net weight MSR42
Muting box
Cantilever floor mounting stand 130 g
1.7 kg
5.7 kg
Housing dimensions 111 x 22,5 x 125 mm (incl. plugs)
Certifications According MSR42
Interfaces Optical Interface
Weight and packaging
Dispatch packaging MSR42
Muting box
Cantilever floor mounting stand 280x 200 x 70 mm
300x 200x 200 mm
Dispatch weight MSR42
Muting box
Cantilever floor mounting stand 350 g
2.3 kg
6.5 kg
OSSD semi conductor outputs (PNP)
Voltage U
N
- 2 V
Current Max 400 mA short-circuit protected and with cross-fault detection
Leakage current I
MAX Off
≤ 0.1 mA (C
LOAD
≤ 3.3 uF)
Max. response time t(C) with U
N
protective mode ≤ 17.3 ms
Output S1-S4 (MSR42 GPIO1 – GPIO4)
Nominal voltage U
N
– 2V (coded) (Short circuit protected)
Current max 100 mA (short-circuit protected)
Leakage current I
MAX Off
≤ 0.05 mA (C
LOAD
≤ 100 nF)
Status Outputs (PNP), MSR42 Info 1, Info 2
Voltage U
N
– 2V
Current max 100 mA (short-circuit protected)
Leakage current I
MAX Off
≤ 0.05 mA (C
LOAD
≤ 4.7 uF)
Inputs (MSR42)
Power supply U
N
+24V DC (EN 60204-1)
at 5% residual ripple 0.85…1.15 U
N
Current consumption Nominal: 70 mA; Rush-In current: max 1.7 A
Max. power consumption at max. supply voltage 2.1 W (semiconductor outputs unloaded)
Controller protection (external) 5 A slow
Control current into: IN 1, IN 2 2 mA each (min.) (in accordance with EN 61131-2)
Minimum voltage at: IN 1, IN 2 11V DC at activated controller (EN 61131-2)
Start pulse duration Min.
Max.
50 ms
5s
Mute sensor time delay > 50 ms
Test pulse duration (min.) Response time x 2
Control current into: GPIO1 – GPIO4 7 mA
Safety Prevention Lamp
Minimum current at Lamp 8 mA with lamp switched on
0.9 A with lamp switched on
Safety Related Parameter
Probability of a dangerous failure per hour PFH 9.0 E-10 1/h
3.0 E-10 1/h
4.0 E-9 1/h MSR42 Main M.
MSR45E
GuardShield Micro 400
