Muting Controller Box Installation and Operating Instructions
17
R
Original instructions
Muting System Examples
Product Part Number Description
Safe 4 PAC Light Curtain Example
Light Curtain 1x 445L-P4S3400YD Safe 4 PAC 3 beam light curtain pair
Muting Box 1x 445L-AMUTBOX1 Muting Controller Box (MSR42)
Light Curtain Patchcord 2x 889D-F5ACDM-1 5 conductor M12 patchcord 1 meter, also offered in 5 and 10 meter lengths (2 required)
Muting sensor 2x or 4x 42EF-P2MPB-Y4
RightSight, Polarized Retro, Red, DC - 2 Complementary LO/DO Outputs, (PNP), 4-pin
Pico QD on 152 mm (6 in.) pigtail (2 or 4 sensors required) muting sensor patchcord
Muting sensor patchcord 2x or 4x 889P-F4ABPM-x 4 conductor M8 patchcord (x = 1, 2, 3, or 5 meter)
Muting sensor bracket 2x or 4x 60-2649 Swivel/Tilt Bracket for RightSight sensors 2x or 4x 889P-F4ABPM-1
Muting sensor reflector 2x or 4x 92-39 Reflector 76 mm (Bracket included in 445L-AMSTDMUT)
If external mute lamp is desired, a mute lamp option with right angle bracket is below
Muting lamp with bracket 1x
855E-24TL7
855E-BVMC
Muting lamp with right angle bracket
Muting lamp patchcord 1x 889P-M4AB-5 4 conductor M8 Pico patchcord, 5 meters
Connection cable power
(PWR/IO)
1x 889D-F8AC-x x = 2, 5, or 10 meter
Connection cable outputs 1x 889D-M5AC-x x = 2, 5, or 10 meter
GuardShield PAC Light Curtain Example
Light Curtain 1x 440L-P4A3400YD GuardShield PAC 3 beam light curtain pair
Muting Box 1x 445L-AMUTBOX1 Muting Controller Box (MSR42)
Light Curtain Patchcord 1x 889D-F4ACDM-1 Transmitter patchcord 1 m, Straight, DC Micro M12-4 conductor
Light Curtain Patchcord 1x 889D-F8ABDM-5 Receiver patchcord 5 m, Straight, DC Micro M12-5 conductor
Muting sensor 2x or 4x 42EF-P2MPB-Y4
RightSight, Polarized Retro, Red, DC - 2 Complementary LO/DO Outputs, (PNP), 4-pin
Pico QD on 152 mm (6 in.) pigtail (2 or 4 sensors required) muting sensor patchcord
Muting sensor patchcord 2x or 4x 889P-F4ABPM-x 4 conductor M8 patchcord (x = 1, 2, 3, or 5 meter)
Muting sensor bracket 2x or 4x 60-2649 Swivel/Tilt Bracket for RightSight sensors muting sensor patchcord
Muting sensor reflector 2x or 4x 92-39 Reflector 76 mm (Bracket included in 445L-AMSTDMUT)
If external mute lamp is desired, one mute lamp option with right angle bracket is below
Muting lamp with bracket
855E-24TL7
855E-BVMC
Muting lamp with right angle bracket
Muting lamp patchcord 889P-M4AB-5 4 conductor M8 Pico patchcord, 5 meters
Muting stand 2x 445L-AMSTD2M
Muting cantilever 2x or 4x 445L-AMSTDMUT
Micro 400 Light Curtain Example
Light Curtain 1x 440L-P4E1200FP 30 mm Micro 400 light curtain pair, 1200 mm
Muting Box 1x 445L-AMUTBOX1 Muting Controller Box (MSR42)
Micro 400 patchcords 2x 445L-AC8PC1 8 pin M12 patchcord with filter, 1 meter, also offered in 3 meter and 5 meter lengths
Muting sensor 2x or 4x 42EF-P2MPB-Y4
RightSight, Polarized Retro, Red, DC - 2 Complementary LO/DO Outputs, (PNP), 4-pin
Pico QD on 152 mm (6 in.) pigtail (2 or 4 sensors required) muting sensor patchcord
Muting sensor patchcord 2x or 4x 889P-F4ABPM-x 4 conductor M8 patchcord (x = 1, 2, 3, or 5 meter)
Muting sensor bracket 2x or 4x 60-2649 Swivel/Tilt Bracket for RightSight sensors muting sensor patchcord
Muting sensor reflector 2x or 4x 92-39 Reflector 76 mm (Bracket included in 445L-AMSTDMUT)
