GuardShield™ Micro 400 Safety Light Curtain User Manual
22
R
Original instructions
GuardShield Micro 400, Cascaded, Profile 20 x 15 mm, Resolution 14 mm
GuardShield Micro 400, Cascaded, Profile 20 x 15 mm, Resolution 30 mm
GuardShield Micro 400, IP69K, tube, Resolution 14 mm
Sensor Pair
Transmitter
Receiver
Resolution
[mm (in.)]
Protection Height A
[mm (in.)]
Weight per pair [incl.
packaging]
445L-C4C0150FP
445L-G4C0150FP
445L-F4C0150FP
14 (0.55)
150 (5.91)
0.8 kg
445L-C4C0300FP
445L-G4C0300FP
445L-F4C0300FP
14 (0.55)
300 (11.81)
0.9 kg
445L-C4C0450FP
445L-G4C0450FP
445L-F4C0450FP
14 (0.55)
450 (17.71)
0.9 kg
445L-C4C0600FP
445L-G4C0600FP
445L-F4C0600FP
14 (0.55)
600 (23.62)
1.0 kg
445L-C4C0900FP
445L-G4C0900FP
445L-F4C0900FP
14 (0.55)
900 (35.43)
1.2 kg
445L-C4C1200FP
445L-G4C1200FP
445L-F4C1200FP
14 (0.55)
1200 (47.24)
1.3 kg
Sensor Pair
Transmitter
Receiver
Resolution
[mm (in.)]
Protection Height A
[mm (in.)]
Weight per pair [incl.
packaging]
445L-C4E0150FP
445L-G4E0150FP
445L-F4E0150FP
30 (1.18)
150 (5.91)
0.8 kg
445L-C4E0300FP
445L-G4E0300FP
445L-F4E0300FP
30 (1.18)
300 (11.81)
0.9 kg
445L-C4E0600FP
445L-G4E0600FP
445L-F4E0600FP
30 (1.18)
600 (23.62)
1.0 kg
445L-C4E0750FP
445L-G4E0750FP
445L-F4E0750FP
30 (1.18)
750 (29.52)
1.1 kg
445L-C4E0900FP
445L-G4E0900FP
445L-F4E0900FP
30 (1.18)
900 (35.43)
1.2 kg
445L-C4E1200FP
445L-G4E1200FP
445L-F4E1200FP
30 (1.18)
1200 (47.24)
1.3 kg
Sensor Pair
Transmitter
Receiver
Resolution
[mm (in.)]
Protection Height A
[mm (in.)]
Max. response time
t
LC
(ms) *
Weight per pair [incl.
packaging]
445L-P4C0150KD
445L-T4C0150KD
445L-R4C0150KD
14 (0.55)
150 (5.91)
14.6 ms
1.45 kg
445L-P4C0300KD
445L-T4C0300KD
445L-R4C0300KD
14 (0.55)
300 (11.81)
18.5 ms
1.5 kg
445L-P4C0600KD
445L-T4C0600KD
445L-R4C0600KD
14 (0.55)
600 (23.62)
26.3 ms
1.7 kg
445L-P4C0900KD
445L-T4C0900KD
445L-R4C0900KD
14 (0.55)
900 (35.43)
34.1 ms
2.3 kg
445L-P4C1200KD
445L-T4C1200KD
445L-R4C1200KD
14 (0.55)
1200 (47.24)
41.9 ms
2.4 kg
