GuardShield™ Micro 400 Safety Light Curtain User Manual
21
R
Original instructions
Catalog Number Configurator
GuardShield Micro 400 Products
The response times (*) are maximum values with no blanking configured. If blanking is configured in the Micro 400 controller, the
response time values could be higher. The times depend on the controller type and the configuration. The real response time may be
faster. Please obtain the exact time from the software "Configuration Tool."
GuardShield Micro 400, Standard, Profile 20 x 15 mm, Resolution 14 mm
GuardShield Micro 400, Standard, Profile 20 x 15 mm, Resolution 30 mm
Sensor Pair Transmitter Receiver
Resolution
[mm (in.)]
Protection Height A
[mm (in.)]
Max. response time
t
LC
(ms) *
Weight per pair [incl.
packaging]
445L-P4C0150FP 445L-T4C0150FP 445L-R4C0150FP 14 (0.55) 150 (5.91) 14.6 ms 0.8 kg
445L-P4C0300FP 445L-T4C0300FP 445L-R4C0300FP 14 (0.55) 300 (11.81) 18.5 ms 0.9 kg
445L-P4C0450FP 445L-T4C0450FP 445L-R4C0450FP 14 (0.55) 450 (17.71) 22.4 ms 0.9 kg
445L-P4C0600FP 445L-T4C0600FP 445L-R4C0600FP 14 (0.55) 600 (23.62) 26.3 ms 1.0 kg
445L-P4C0750FP 445L-T4C0750FP 445L-R4C0750FP 14 (0.55) 750 (29.52) 30.2 ms 1.1 kg
445L-P4C0900FP 445L-T4C0900FP 445L-R4C0900FP 14 (0.55) 900 (35.43) 34.1 ms 1.3 kg
445L-P4C1050FP 445L-T4C1050FP 445L-R4C1050FP 14 (0.55) 1050 (41.33) 38.0 ms 1.3 kg
445L-P4C1200FP 445L-T4C1200FP 445L-R4C1200FP 14 (0.55) 1200 (47.24) 41.9 ms 1.3 kg
Sensor Pair Transmitter Receiver
Resolution
[mm (in.)]
Protection Height A
[mm (in.)]
Max. response time
t
LC
(ms) *
Weight per pair [incl.
packaging]
445L-P4E0150FP 445L-T4E0150FP 445L-R4E0150FP 30 mm (1.18) 150 (5.91) 12.4 ms 0.8 kg
445L-P4E0300FP 445L-T4E0300FP 445L-R4E0300FP 30 mm (1.18) 300 (11.81) 13.9 ms 0.9 kg
445L-P4E0450FP 445L-T4E0450FP 445L-R4E0450FP 30 mm (1.18) 450 (17.71) 15.5 ms 0.9 kg
445L-P4E0600FP 445L-T4E0600FP 445L-R4E0600FP 30 mm (1.18) 600 (23.62) 17.0 ms 1.0 kg
445L-P4E0750FP 445L-T4E0750FP 445L-R4E0750FP 30 mm (1.18) 750 (29.52) 18.5 ms 1.1 kg
445L-P4E0900FP 445L-T4E0900FP 445L-R4E0900FP 30 mm (1.18) 900 (35.43) 20.2 ms 1.2 kg
445L-P4E1050FP 445L-T4E1050FP 445L-R4E1050FP 30 mm (1.18) 1050 (41.33) 21.7 ms 1.3 kg
445L-P4E1200FP 445L-T4E1200FP 445L-R4E1200FP 30 mm (1.18) 1200 (47.24) 23.3 ms 1.3 kg
445L- 0150 P F C 4 P
Connector Option
P = Pigtail with micro QD connector
D = M12, 8-pin QD
Environmental Rating:
F = IP54
K = IP69K
Protective Height (mm)
0150
0300
0450
0600
0750 0900
1050
1200
C = 14 mm resolution
E = 30 mm resolution
Category Type 4
P = Pair; T = Transmitter; R = Receiver
C= Cascade; G = Cascade transmitter; E = Cascade receiver
Bulletin Number
