31
Specifications
Model IK400 IK400W IM400 IM400W
Temperature control method Draft circulation
Shaking method Horizontal back-and-forth Horizontal rotating
Operating temperature range 5° to 60°C
Temperature control
accuracy
±0.5°C (at 37°C)
Temperature distribution
accuracy
±1.0°C (at 37°C)
Shaking speed Approximately 30 to 200 rpm
Perfor-
mance
* 1
Shaking amplitude 70 mm
Heater 500-W iron-chrome wire heater
Fan Axial fan with a 14/13-W (50/60 Hz) motor
Shaker motor Fully enclosed 60-W motor
Interior JIS SUS304 stainless steel
Heat insulator Expanded polystyrene (styrene foam)
Window Not furnished Furnished Not furnished Furnished
Freezer 130-W, air-cooled sealed freezer (R130a coolant)
Const-
ruction
Shaking table JIS SUS304 stainless steel. The tray must be used.
Temperature control PID control using a microcomputer
Temperature setting and
display
Digital setting using the increment and cursor keys. 7-segment green LEDs;
display of 3 digits.
Speed setting and display Analog setting using a turning knob. 7-segment green LEDs; display of 2 digits.
Temperature sensor Platinum resistance temperature detector
Control
unit
Auxiliary function Defrost function (continuous 10-minute defrosting after switch-on)
Featured in controller Self-diagnostics (sensor, heater, TRIAC, main relay) Safety
systems
Security Door switch (“door safety” function), earth leakage breaker
Dimensions* 2 710 (W) X 650 (D) X 920 (H) mm
Maximum load Nine 500-ml Erlenmeyer flasks (up to 6 kg(f))
Maximum load on optional
shelf
Approximately 5 kg/shelf
Power supply 100 V AC, 50/60 Hz, 9 A
Other
specifi-
cations
Weight Approximately 125 kg(f)
Accessories Instruction manual
*1: Reference conditions: temperature 23°±5°C, humidity 65±20%, and with the rated power supply
*2: Excluding protruding portions
