P O W E R M O N I T O R P A C K A G E O N L Y
POWER MONITOR OPTION HG7 I, O, & M Manual 33
12. You can step through the menu only in the "UP" direction. If you wish to return to an item once
you have stepped past it, step past "---" without pressing the SELECT key to return to "1A."
Table 7 – Setup Menu
Parameter
Name
Description Range
Factory
Default
Setting
--- Enter/Exit Factory Setup Mode
1 A Fault Delay Time 1-60 SEC 30
2 A Restart Lockout Time 1-60 SEC 30
3 A Filter KVAR Rating (Nameplate) 3.0-120 KVAR (Nameplate)
4 A Operating Frequency (Nameplate) 50 or 60 Hz (Nameplate)
5 A Fast Trip Overcurrent % Set 100%-199% 180
6 A Slow Trip Overcurrent % Set 100%-199% 160
7 A Low Trip Undercurrent % Set 1%-100% 80
8 A Nominal Line to Line Voltage (Nameplate) 200 - 600 VOLTS (Nameplate)
9 A Line Current Rating (Nameplate) 0 or 5 - 480 AMPS (Nameplate)
10A Security Code 000 – 999 000
11A Calibration Mode 0 = Normal Operation
1 = Calibration Mode
0
Changing the Security Code
The factory default security code is “000.” To change this code, enter the Setup Menu and proceed as
follows:
13. Use the UP key to step to parameter “10A.”
14. Press and release the SELECT key. The present security code will be displayed.
15. Use the DOWN key to change digit one to the first digit of the new code.
16. Press the UP key once to select digit two.
17. Press the DOWN key to change digit two to the second digit of the new code.
18. Press the UP key once to select digit three.
19. Press the DOWN key to enter digit three to the third digit of the new code.
20. Press the UP key once and the original code will be displayed.
21. Repeat the steps 3 to 7 to enter the new code a second time.
22. After completing step 7, press the SELECT key.
23. If the new code has been properly entered twice, the display will show “10A” and the new code
will be saved.
24. If the two entries of the new code did not agree, "err" will be displayed. Press any key and the
display will show “10A.” If you press and release the SELECT key, you can see that the code
remains unchanged. You can start over at step 3.
NOTE: If the code is changed and the new code is lost, you will no longer have
access to the Setup Menu. The unit will have to be returned to the factory to
be reprogrammed to the default security code.
