I N T R O D U C T I O N
INTRODUCTION HG7 I, O, & M Manual 15
Product Technical Specifications
Table 2 lists the major technical specifications for the HG7 Harmonic Filter.
Table 2 – HG7 ST and STC Option Harmonic Filter Technical Specifications
Voltage ratings 240, 480 and 600 V, 3 ph, 60 Hz
380 – 415 V, 3 ph, 50 Hz
kVar ratings 3 to 270 kVar depending on voltage.
Load types 3-phase diode bridge rectifier loads such as PWM AC drives
Load power range 7.5 -900 Hp depending on voltage, 4–710kW
See Rating and Dimension tables.
Current ratings The included series reactors can tolerate 200% of rated current for at
least 3 minutes.
SCCR (short circuit current
rating) Standard rating is 10kA.
Maximum elevation 3,000 feet (1,000 meters) as standard.
Maximum ambient operating
temperature 50°C (122°F) – Open Panel; 40°C (104°F) – Enclosed Panel.
Product must be equipped with special cooling provisions for
operation above this temperature.
Maximum ambient storage
temperature 60°C (140°F)
Maximum humidity,
operating or storage 95%, non-condensing.
Enclosure options UL Type 1 enclosure
UL Type 3R enclosure
Agency approvals or
certifications UL and cUL Listed to UL508A
Insertion Impedance +/- 10% at full load current
Fusing and protection: All units have internal fuse protection for the harmonic filter circuit.
Capacitors Oil filled high endurance design (no PCBs)
