I N T R O D U C T I O N
INTRODUCTION HG7 I, O, & M Manual 11
Table 1c – Fuse Specifications for HG7 480 Volt Models
HG7 Rating
(HP)
kVar
Power Circuit
Fuse Ratings
Amps Type
10 3 10
Class CC Bussmann
type KTK-R
or equivalent
15 5 15
20 6 15
30 10 30
40 15 30
60 20 40
Class T
Bussmann
type JJS
or equivalent
75 25 50
100 30 60
125 40 80
150 45 100
200 60 125
250 75 175
300 90 200
350 105 225
400 120 250
450 135 300
600 180 400
700 210 450
800 240 500
900 270 600
Table 1d – Fuse Specifications for HG7 600 Volt Models
HG7 Rating
(HP)
kVar
Power Circuit
Fuse Ratings
Amps Type
15 5 10 Class CC Bussmann
type KTK-R
or equivalent
30 10 25
50 15 30
60 20 35
Class T
Bussmann
type JJS
or equivalent
75 25 40
100 30 50
125 40 70
150 45 80
200 60 100
250 75 125
300 90 150
350 105 175
400 120 200
450 135 250
500 150 250
600 180 300
700 210 350
800 240 400
900 270 450
