Skyjacker 9296 User Manual

Hardware bag breakdown: part # hb-7296

background image

1999 - 2006 GM K1500 4WD

Dual Steering Stabilizer

Part # 7296 / 9296

I-7296 REV3 2-14

Pg 1

www.skyjacker.com

RequiReD Tool liST:

Safety Glasses

Metric / Standard Wrenches & Sockets

Drill / 5/16" Drill Bit

Measuring Tape

Torque Wrench

Before beginning the installation, thoroughly & completely read these instructions & the enclosed

driver’s WARNING NOTICE. Affix the WARNING decal in the passenger compartment in clear view
of all occupants. Please refer to the Parts List to insure that all parts & hardware are received prior
to the disassembly of the vehicle. If any parts are found to be missing, contact SKYJACKER®

Customer Service at 318-388-0816 to obtain the needed items. If you have any questions or

reservations about the installation of this product, contact SKYJACKER® Technical Assistance at

318-388-0816.

Component Box Breakdown:

Part #: 7296 / 9296

item #

Description

qty

item #

Description

qty

7500WS

WHITE STEERING DAMPER

2

BTIE-K

BLACK BOOT TIE

2

(included With 7296)

(included With 9296)

9500WS

SILVER STEERING DAMPER

2

HSS

HYDRO SHOCK DECAL

2

(included With 9296)

(included With 7296)

B12RS

RED BOOT

2

SSD

SILVER STABILIZER DECAL

2

(included With 7296)

(included With 9296)

B12KS

BLACK BOOT

2

HB-7296

HARDWARE BAG: 7296 / 9296

1

(included With 9296)

I-7296

INST SHEET: 7296 / 9296

1

BTIE

RED BOOT TIE

2

(included With 7296)

Hardware Bag Breakdown:

Part # HB-7296

item #

Description

qty

item #

Description

qty

7298-MB

MAIN BRACKET

1

58X5FTB

5/8 X 5 FINE THREAD BOLT 2

C966DSST-S TAB BRACKET

2

58FTN

5/8 FINE THRD LOCK NUT

2

140629

EB6 STUD BAG - P932/140629

2

58SAEW

5/8 SAE WASHER

4

516X114X134U 5/16 X 1 1/4 X 1 3/4 U-BOLT RD

2

142120

STAB WASH PKG

2

516CTN

5/16 COARSE THRD LOCK NUT

4

HOURGLASS 5/8 HOURGLASS 5/8 BUSHING

2

516SAEW

5/16 SAE WASHER

4

STEM BUSH-SST STEM BUSHING

4

38X1TCFB

3/8 X 1 THRD-CUT FLG BOLT

2

12SAEW

1/2 SAE WASHER

4
