Installation:
1. Park the vehicle on a level concrete or asphalt surface with the front tires / wheels pointing
straight forward.
2. Set the emergency brake & block the rear tires / wheels.
3. Install the body end of the new Skyjacker steering stabilizer onto bracket “A”.
4. Extend the new Skyjacker steering stabilizer shaft out 4”(exactly half way) & attach bracket “B” to
the tie rod using the supplied u-bolt & 3/8” bolt. The supplied 3/8” bolt will be attached to the
lower forward hole on bracket “B”. The supplied u-bolt will be attached around the tie rod &
through bracket “B”.
Shock Stud
Stem Bushings
Retaining Washer
Retaining Washer
Bracket
Retaining Nut
Bracket “B”
Bracket “A”
I-7070-7175 Pg 2
