Skyjacker 7119 User Manual
Jeep, Dual stabilizer kit installation instructions
1.
Place wheels in straight forward position.
2.
Remove OEM Steering Stabilizer. Install NEW Stabilizer in place using hardware provided.
3.
To install 7119 Stabilizer, place boot onto stabilizer, but do not secure boot with boot tie at this
time.
4.
Install both brackets onto each end of stabilizer using bushing & washer packs provided.
5.
Pull the stabilizer rod out EXACTLY half-way out. Stabilizer must be kept out exactly half-way
during installation.
6.
Mount stabilizer in place (refer to photo). Install U-bolts (
5
⁄
16
" x 1
1
⁄
4
" x 2
1
⁄
4
" around track bar and
5
⁄
16
" x 1" x 2
1
⁄
4
" around tie rod assembly), but do not tighten yet.
NOTE: Be sure the passenger bracket is located directly below the tie rod clamp (see
arrow below.) After brackets are in position, tighten the U-bolts.
7.
Turn wheels fully to the left & right to make sure stabilizer is adjusted properly (refer to step #5.)
8.
Place boot tie around boot & secure.
SEAT BELTS SAVE LIVES. PLEASE WEAR YOUR SEAT BELT
1
IJ-7219 (Rev. 6/98)
JEEP
®
DUAL STABILIZER KIT
INSTALLATION INSTRUCTIONS
Kit #: 7219
➜
➜
➜
#7009
➜ #7119
Part #: 7009
1 - 7400WS Stabilizer
2 - Hourglass 5/8" Bushings
1 - 142121 Sleeve (51792)
1 - P837 Tapered Stud Bag
1 - Boot & Boot Tie
Part #: 7119
1 - 7900WS Stabilizer
2 - 83161 Mounting Brackets
4 - Stem Bushings
2 - 142120 Washer/Nut Packs
2 -
5
⁄
16
" x 1" x 2
1
⁄
4
" U-bolts, Nuts & Washers
2 -
5
⁄
16
" x 1
1
⁄
4
" x 2
1
⁄
4
" U-bolts, Nuts & Washers
1 - Boot & Boot Tie
