Pg 4
Rear Installation:
15. Block the front tires & raise the rear of the vehicle. Properly
support the frame rails using jack stands & remove the rear tires
/ wheels. (See Photo # 10)
16. Disconnect the brakeline brackets & remove the rear shocks &
sway bar end link from the axle to allow for the installation of the
new Skyjacker rear coils. Disconnect the track bar from the
frame. (See Photo #11).
17. Remove the factory coil spring & replace with the new Skyjacker
rear coil springs. Note: Be sure to retain the upper bump stop as
shown. (See Photo #12)
18. Re-attach the track bar & brakeline brackets. Install the new
Skyjacker sway bar end links. Install using the supplied
hardware. (See Photo #13)
19. Install the new Skyjacker rear shocks. (See Photo #14)
20. Install the rear tires / wheels & lower the vehicle to the ground.
Photo #10
Photo #11
I-FJ730ST
Photo #12 Photo #13
Photo #14
