RaySafe i2 dose manager user manual – Get to know dose manager
Figure 15. Graph legend
SeleCtIonS In A doSe GRAPH
Figure 16. A selection in a dose graph
make selections in a dose graph to analyze a certain time span further, see section “make a selection in a
graph” on page 41. when you have made a selection, the following information is available in the graph
legend:
Table 22. Dose graph selections
ITEm DEsCRIpTION
Selection summary An overall description about the selection.
