RaySafe ThinX RAD - Manual

RaySafe ThinX RAD
User ManUal RaySafe ThinX measures X-ray radiation. The instrument is always
on, triggered by radiation. You don’t need any correction tables,
since the active compensation feature automatically applies correc-
tions for variation in beam filtration. BaTTeRY ReplacemenT
When the yellow leD is blinking,
please replace the battery:
1. Remove the battery cover.
2. Replace the battery (cR2450).
3. put the cover back. The instru-
ment is ready to use.
cleaning
Use a damp cloth for cleaning.
inSTRUmenT veRSionS
This manual is valid for 1302024-a, 1302025-a and 1302026-a.
SUppoRT
Do not hesitate to contact Unfors RaySafe for support:
Technical support
+49 731 175 492-20
[email protected]
Service
+46 31 719 97 10
[email protected]
2
1
3
position RaySafe ThinX with the sensor area
centered in the X-ray field.
expose.
Read the values on the display.
if the detected waveform is pulsed, the num-
ber of pulses will automatically be displayed.
© 2012.
08 Unfors
ray
safe 5000094-B
