● This lamp is a hanging type and uses a bracket. If using it upright, set the bracket up correctly so that the PIAA logo is
properly displayed.
● In order for the lamp to perform at its full potential, use relay harnesses manufactured by PIAA.
● All work procedures should be carried out in a location with adequate space. Place the shift lever in neutral or in the parking
position. Turn off the engine and set the side brake.
● Make sure the engine compartment is adequately cool before starting work. Do not begin work if engine parts such as radiator,
oil-cooler or turbo part are still hot.
● Be extremely careful when handling the lamp and relay harness. If dropped or excessive shock is applied to the lens, bulb or
relay harness, it may cause irreversible damage.
● Do not add additional holes to the main body of the lamp. Also, do not apply adhesives or stickers to the lamp parts.
● Do not modify the lamp harness or the relay harness in any way. Such modifications may cause it to overheat or short. In some
cases, it may cause the vehicle to catch fire. PIAA will not be liable for damage caused by such modifications.
● When removing the battery terminals, do not touch the (-) and (+) terminals simultaneously. An electrical shock may occur.
Wear rubber gloves when carrying out such work procedures.
● Make sure the (-) and (+) terminals do not make contact with metal. It can be extremely dangerous if a short occurs.
● Make sure all bolts are tightly secure. If there are any loose bolts tighten them accordingly.
● After installing the lamp, adjust the lamp so the beam shines at least 40m in front of the vehicle. Also, adjust the lamp a little
toward the left so that it does not shine directly into the eyes of the opposing driver of a vehicle. (as traffic laws stipulate -
refer to p.8 for adjustment procedures)
● After installing the lamp, make sure the headlamps, wipers and horn are working normally.
● When the battery terminal is removed, memory related to the clock, radio, audio system etc, will be affected. After all work
procedures are completed, reset to the original settings.
(For adjustment procedures refer to your car s instruction manual)
Please read the installation procedures thoroughly beforehand.
● Before you begin always remove the (-) and (+) terminals.
Always remove the (-) terminal first and make sure a short does not occur.
● When removing the battery terminals, always turn the key to OFF and remove it. Turn all other electrical units off such as
the light switch.
● When removing the battery terminals, if a cord (for an electrical unit) is connected, wind a length of vinyl tape around the
(-) and (+) terminals to clearly identify them.
● Verify the (+) terminal (white) and earth (black) before connecting.
● Do not obtain (+) voltage from the alternator.
● When doing wiring work, strictly follow the cautionary points mentioned below. Incorrect or faulty wiring may cause the lamp
to operate improperly. In some cases, it may cause the vehicle to catch fire.
Caution Regarding Wiring / Please read thoroughly
● If the lens is cracked or damaged in any way, verify whether there is any damage to the harness or the relay harness that it is
connected to. If there is any damage to the cord covering, replace it immediately.
● Avoid injury when replacing the harness and relay harness. Please dispose of it as a non-combustible item.
● If a significant amount of water seeps in it may cause irreversible damage to the bulb.
Please refer to 【7】Troubleshooting section of this manual.
