Page 6

4
Back
1 Main battery lock, follow the
illustrations on Pocket PC to use.
2 Main battery, follow the arrow’s
direction to slide and release it.
Merchandise label on the top of
battery cover.
3 Note the cut-corner position and
insert the SIM card accordingly
into the retainer.
4 Turn over the retainer and insert
the SIM card into the slot.
Note that the metal surface of the
SIM card should face downward.
5 Back-up power switch, follow the
illustrations on Pocket PC to use.
6 Cradle connection port
y
Please note carefully!
1. You need to turn on back-up power switch when you use this device for
the first time. When back-up power switch is set to be “ON”, the system
operation will temporarily rely on back-up battery to supply its power if
you need to pull out or replace main battery. Back-up battery is charged by
main battery.
2. If back-up power switch is set to be “OFF”, the back-up battery will not
function. Once the main battery is taken out, the device will only retain
Microsoft Windows and manufacture’s pre-installed programs. Any other
data input, programs newly installed, and customised settings setup by you
will be lost.
1
2
3
4
2
5
6
