5
Trigger key
The trigger key activates the laser scanner. There are 5 buttons available to
define as trigger key.
Launch button 1 = recording button
Launch button 2 = right ‘today screen’ hot key
Launch button 3 = left ‘contact’ hot key
Launch button 4* = right button
Launch button 5* = left button
* Note: button 4 and 5 can not be defined
for the GSM/GPRS models
Tab Barcodes
Tick on the box to set the label type ON or OFF.
The following bar code label types are supported:
Type Default
setting
CODABAR
CODE-39
CODE-93
CODE-128
EAN
IATA
Industrial 2 of 5
Interleaved 2 of 5
Leatus
MSI PLESSEY
Matrix 2 of 5
Scode
Telepen
UK PLESSEY
UPC ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
All addons OFF
