dca70SSJU4i 60 hz generator• operation manual — rev. #2 (04/09/14) — page 95
FUeL taNk assy.
no. part no. part name QtY. remarKs
1 M2364000002 FUEL TANK 1
1-1 0605505070 FUEL TANK CAP 1
1-2 0605501079 FUEL SENDER UNIT 1
1-2A 0605516090 GASKET 1
1-2B 7538070 MACHINE SCREW 5
2 M2363200704 TANK BAND 3
3 M2363200804 TANK BAND 3
4 M9310500104 SUPPORTER SHEET 6
5 011008020 HEX. HEAD BOLT 6
6 020108060 SELF-LOCKING NUT 6
7 0222100710 TANK SHEET 5
8 0191302200 VENT HOSE 1
9 0605515109 HOSE BAND 2
10 0191301100 SUCTION HOSE 1
11 0191300700 RETURN HOSE 1
12 0605515109 HOSE BAND 2
13 Y0602042602 HOSE JOINT 1
14 Y0605512182 HOSE JOINT 1
15 0605515189 HOSE BAND 2
