dca70SSJU4i 60 hz generator• operation manual — rev. #2 (04/09/14) — page 83
no. part no. part name QtY. remarKs
29 Y0601807631 FREQUENCY METER, 240V 45~65HZ 1
30 Y0601817034 AC AMMETER, 0~150A/300A: 5A 1
31 Y0601806947 AC VOLTMETER, AC 600V 1
32 0601801040 CHANGE-OVER SWITCH, AMMETER 1
33 0601801041 CHANGE-OVER SWITCH, VOLTMETER 1
34 Y0601810170 PANEL LIGHT, 12V 1
35 0027104020 MACHINE SCREW 2
35A OEMAA8 SELF-LOCKING NUT 2
36 Y0602120569 GAUGE UNIT ASSY 1
37 Y0602202644 CONTROLLER 1
38 Y0206707000 HEX. NUT 8
38A Y0044807000 WASHER, LOCK 8
39 M1224100104 STOPPER 1
40 0027105010 MACHINE SCREW 2
41 M2213500704 CONTROL BOX COVER 1
42 0016906016 HEX. HEAD BOLT 4
43 M2213602704 SWITCH BRACKET 2
44 0021004040 MACHINE SCREW 4
44A 0040004000 WASHER, LOCK 4
44B 58042 WASHER, FLAT 4
44C OEMAA8 HEX. NUT 4
45 7538070 MACHINE SCREW 4
45A OEMAA8 HEX. NUT 4
46 0016906016 HEX. HEAD BOLT 4
47 M2213602804 SWITCH COVER 1
48 011106015 HEX. HEAD BOLT 6
49 M2213602904 SWITCH COVER 1
49-1 0228800165 SEAL RUBBER 1
49-2 0228800115 SEAL RUBBER 1
49-3 0317700180 WEATHER STRIP 1
50 0016906016 HEX. HEAD BOLT 4
51 M2270100104 SELECTOR SWITCH 1
51A M2550001604 DECAL: SELECTOR SWITCH 1
51B M2550001704 DECAL: SELECTOR SWITCH 1
52 011106015 HEX. HEAD BOLT 12
52A 0040506000 TOOTHED WASHER 1
53 M2224000003 CONTROL PANEL 1
54 0027105010 MACHINE SCREW 4
55 M9220100004 SET SCREW 2
55A 0080200007 E-SNAP RING 2
56 0602202597 RELAY, STARTER 1
57 0027105015 MACHINE SCREW 1
58 M2247700204 WIRE HARNESS, GENERATOR 1
59 M2358200102 WIRE HARNESS, ENGINE 1
60 EE55989 EMERGENCY STOP SWITCH ..........................1................OPTION
CONtrOL bOx assy. (CONtiNUeD)
