dca70SSJU4i 60 hz generator• operation manual — rev. #2 (04/09/14) — page 113
traiLer trLr70Use assy. (OptiON)
no. part no. part name QtY. remarKs
1 EE57460 FRAME ASSY 1
2 EE43182 ADAPTER, FRAME, ELECTRIC, CENTERED 1
3 EE43524 SCREW, CAP, HEX HD, 5/8 -18 X 2" GRD 8 6
4 EE43528 NUT, SELF-LOCKING, 5/8 -18, GRD 8, ZN 14
5 EE43606 WASHER, FLAT, 5/8" ZN 16
6 EE44418 SCREW, CAP, HEX HD, 5/8 -11 X 5" GRD 8 2
7 EE44419 NUT, SELF-LOCKING, 5/8 -11, GRD 8, ZN 2
8 EE55967 AXLE, ELECTRIC RUBBER TORSION, 3.5K LBS. (1,588KG) 2
9 EE34256 LIGHT, TAIL, REAR RIGHT (CURB SIDE) 1
10 EE34257 LIGHT, TAIL, REAR LEFT (STREET SIDE) 1
11 EE43536 LIGHT, LICENSE 1
12 EE43535 LIGHT, CLEARANCE/SIDE MARKER, AMBER 2
13 EE43369 FENDER W/ SLOTS, ROUNDED 2
14 EE43527 SCREW, CAP, HEX HD 3/8-16 X 1" GRD 8 8
15 EE43529 NUT, SELF-LOCKING 3/8-16, GRD 8, ZN 8
16 EE43530 WASHER, FLAT, 3/8", ZN 16
17 EE43524 BOLT, CAP, HEX HD, 5/8 -18 X 2" GRD 8 8
18 EE55105 KIT, WIRE HARNESS, 4-WAY FLAT 1
19 EE55278 ELECTRIC, BRAKE HARNESS KIT 1
20 EE40139 TIRE/WHEEL ASSY, ST205/75D15 "C", W/ 5-LUG NUTS ....... 4 ........... INCLUDES ITEM W/$
21 EE43517 JACK, SWIVEL 3K LBS. (1,361 KG) 1
22 EE57446 JACK, SQUARE 8K LBS. (3,629 KG) ....................................... 1 ........... OPTIONAL
23 EE43513 CHAIN, TRANSPORT, 3/8" X 42" W/ HOOK 2
25 EE43254 COUPLER, 2" BALL 10K LBS. (4,536 KG) ............................... 1 ........... OPTIONAL
30 EE43253 COUPLER, 2-5/16" BALL 14K LBS. (6,350 KG) ....................... 1 ........... OPTIONAL
31 EE36264 COUPLER, 3" PINTLE 20K LBS. (9,072KG) ............................ 1 ........... OPTIONAL
32$ 29194 NUT, LUG 1/2-20 TAPERED CONE, PLTD 20
33 49928 BRACKET, LF/RR FENDER 2
34 49929 BRACKET, RF/LR FENDER 2
35 0205 SCREW, HHC, 3/8-16 X 1" 12
36 0166 A WASHER, LOCK, 3/8 MED 12
37 701472 PULL PIN ASSY 1
38 EE55276 6-POLE LEAD, ELECTRIC BRAKE 1
39 WASHER, FLAT, 7/16” .............................................................. 4 ........... OBTAIN LOCALLY
40 BOLT, 7/16” x 1½” GRD 8 ......................................................... 4 ........... OBTAIN LOCALLY
41 EE57470 BRACKET, CROSS MEMBER 1
41A BOLT, 3/8” x 1-½” GRD 5 .......................................................... 8 ........... OBTAIN LOCALLY
41B WASHER, FLAT, 3/8” ................................................................ 8 ........... OBTAIN LOCALLY
41C NUT, LOCK, 3/8” ....................................................................... 8 ........... OBTAIN LOCALLY
42 NUT, PLAIN 7/16” ..................................................................... 4 ........... OBTAIN LOCALLY
43 NUT, 1/2-13 ............................................................................... 1 ........... OBTAIN LOCALLY
44 WASHER, FLAT 1/2"................................................................. 1 ........... OBTAIN LOCALLY
45 BOLT, HEX HD., 1/2-13 X 1-3/4" ............................................... 1 ........... OBTAIN LOCALLY
46 BOLT, HEX. HD., 1/2-13 X 1-1/4" .............................................. 1 ........... OBTAIN LOCALLY
47 EE56008 PLATE, JAM, SAFETY CHAIN 2
48 NUT, 1/2-13 ............................................................................... 1 ........... OBTAIN LOCALLY
49 EE43519 KIT, BREAKAWAY, ELECTRIC 1
