Control box assy – Multiquip DCA70SSJU4i User Manual
Page 81
dca70SSJU4i 60 hz generator• operation manual — rev. #2 (04/09/14) — page 81
CONtrOL bOx assy.
no.
part no.
part name
QtY.
remarKs
1
M2214000102
CONTROL BOX
1
1-1
0330000180
EDGING
2
1-2
0330000210
EDGING
1
1-3
0330000300
EDGING
2
1-4
0330000320
EDGING
1
1-5
Y0330000175
EDGING
1
2
Y0601808833
CIRCUIT BREAKER, 3P, 200A
1
3
0021004070
MACHINE SCREW
2
4
0601823863
RELAY UNIT
2
5
7538070
MACHINE SCREW
4
6
Y0601820608
AUTOMATIC VOLTAGE REGULATOR
1
6A
Y0601806683
FUSE, 250V, 8A
1
7
0027105015
MACHINE SCREW
4
8
Y0601809693
CURRENT TRANSFORMER, 150/5A
3
9
011206020
MACHINE SCREW
6
10
0601820847
OVER CURRENT RELAY
1
11
0601820848
OVER CURRENT RELAY, DB25/25A
1
12
0027104020
MACHINE SCREW
2
12A
OEMAA8
SELF-LOCKING NUT
2
13
Y0601872140
HOLDER, FUSE
1
13A
Y0601806607
FUSE, 40A
1
14
0027105015
MACHINE SCREW
1
15
Y0601802219
HOLDER, FUSE, F-65-AD 1P
1
15A
0601806671
FUSE, 15A
1
16
0027104020
MACHINE SCREW
1
17
LY2DUS12VDC
RELAY, DC12V
1
17A
PTF08A
BASE
1
17B
PYCA1
CLIP
2
18
0027104020
MACHINE SCREW
2
19
0601815153
TERMINAL BLOCK
1
20
0027104020
MACHINE SCREW
2
21 0601821370 RECTIFIER
1
22
0027105020
MACHINE SCREW
1
23
0601831205
PUSH BUTTON SWITCH
1
24
82608
TOGGLE SWITCH
1
25
0601830710
TOGGLE SWITCH
1
26
0602103092
ALARM LAMP
1
26A
0601810277
BULB, DC18V
1
27
0601840073
RHEOSTAT (VOLTAGE REG.) 2W 1K OHM
1
28
0601840100
KNOB
1
