Muffler assy – Multiquip DCA70SSJU4i User Manual
Page 93

dca70SSJU4i 60 hz generator• operation manual — rev. #2 (04/09/14) — page 93
MUFFLer assy.
no.
part no.
part name
QtY.
remarKs
1
RE548114
DEVICE, AFTER TREATMENT
1
1-1
Y0602330202
AFTER TREATMENT SENSOR
1
1-2
Y0602330200
JOINT, SIZE 6
1
1-3
Y0602330201
JOINT, SIZE 8
1
1-4
Y0602330000
FLEXIBLE LINE, SIZE 6, L=18"
1
1-5
Y0602330001
FLEXIBLE LINE, SIZE 8, L=27"
1
2
M2331400304
SENSOR BRACKET
1
3
011008020
HEX. HEAD BOLT
7
4
0602325022
PIPE BAND, 3"
1
5
M2334100003
TAIL PIPE
1
6
M2331400404
MUFFLER BAND
2
7
020108060
SELF LOCKING NUT
2
8
M2331400203
AFTER TREATMENT BRACKET
1
9
011008020
HEX. HEAD BOLT
6
10
RE528112
GASKET
1
11
RE289839
V-BAND CLAMP
1
12
M2331400104
COVER, EXHAUST PIPE
1
13
M2331400004
COVER, EXHAUST PIPE
1
14
011008020
HEX. HEAD BOLT
4
15
0602326060
U-BOLT, 3"
1
16
M2331400504
EXHAUST HEAT SHIELD
1
17
Y0272000900
HEAT SHIELD TAPE
1
18
M2331400604
EXHAUST HEAT SHIELD
1
19
Y0272000320
HEAT SHIELD TAPE
1
20
Y0602325051
METAL CABLE TIE
8
21
M2334000003
EXHAUST PIPE
1
22
R531297
GASKET
1
23
0019110030
HEX. HEAD BOLT
3
23A
0042310000
WASHER, LOCK
3
