dca70SSJU4i 60 hz generator• operation manual — rev. #2 (04/09/14) — page 89
OUtpUt terMiNaL assy.
no. part no. part name QtY. remarKs
1 M3230700003 TERMINAL PANEL 1
2 M9220100304 OUTPUT TERMINAL BOLT 5
3 0801830804 TIE BOLT 5
4 0039316000 HEX. NUT 10
5 0040016000 WASHER, LOCK 15
6 0401450160 WASHER, FLAT 20
7 0016908035 HEX. HEAD BOLT 5
8 M2237100103 3-PHASE OUTPUT TERMINAL COVER 1
9 M3236100104 OUTPUT WINDOW 1
10 0605010040 HINGE 2
11 0027103010 MACHINE SCREW 4
11A 0207003000 HEX. NUT 4
11B 0041203000 WASHER, FLAT 4
12 0027103010 MACHINE SCREW 4
12A 0207003000 HEX. NUT 4
13 M9220100804 SET SCREW 2
13A 0040006000 WASHER, LOCK 2
13B 952404470 WASHER, FLAT 2
13C 0080200005 E-SNAP RING 2
14 0016906016 HEX. HEAD BOLT 4
15 M3236400004 RUBBER, CABLE OUTLET COVER 1
16 M3236300004 SUPPORTER, CABLE OUTLET COVER 1
17 011206020 HEX. HEAD BOLT 6
18 0601815194 TERMINAL BLOCK 1
19 7538070 MACHINE SCREW 2
20 0603306775 BLIND PLUG 2
21 7538070 MACHINE SCREW 4
22 0601870440 CIRCUIT BREAKER, 1P, 20A 2
23 0601870441 CIRCUIT BREAKER, 2P, 50A 3
24 M1260700504 BREAKER FITTING COVER 1
24-1 0222100100 CUSHION RUBBER 2
25 0016906016 HEX. HEAD BOLT 2
26 0601814013 RECEPTACLE, 125V, 20A 2
27 Y0601814014 RECEPTACLE, 250V, 50A 3
28 7538070 MACHINE SCREW 10
28A OEMAA8 HEX. NUT 10
29 M2453400004 COVER 1
30 0016906016 HEX. HEAD BOLT 6
31 M2237100003 TERMINAL COVER 1
32 012212045 HEX. HEAD BOLT 2
33 031112230 WASHER, FLAT 6
34 0030012000 HEX. NUT 2
35 Y0605050060 CONICAL WASHER, LOCK 2
36 M4236100604 INSULATING COVER 1
37 M4236400304 SUPPORTER, INSULATING COVER 1
38 0016906016 HEX. HEAD BOLT 2
39 0040508000 TOOTHED WASHER 1
40 0019208025 HEX. HEAD BOLT 1
41 EE6176 RECEPTABLE, FLANGE NEMA 5-15 ................2................OPTION
