dca70SSJU4i 60 hz generator• operation manual — rev. #2 (04/09/14) — page 109
3ø 600 VaC traNsFOrMer assy. (OptiON)
no. part no. part name QtY. remarKs
1 EE5972 BUSHING, PLASTIC, 1-1/2" 4
2 EE57531 KIT, NEUTRAL, BUS BAR 1
3 EE57530 ENCLOSURE, NEMA 3R CIRCUIT BREAKER 1
4 EE52419 CIRCUIT BREAKER, 70 AMP 1
5 EE57532 MECHANISM, CIRCUIT BREAKER OPERATION 1
6 EE57533 SHAFT 1
7 EE57758 LABEL, VINYL, 600V 1
8$ SCREW 2
9 EE57534 HANDLE, EXTERIOR ............................................................... 1 ........... INCLUDES ITEM W/ $
10 EE57538 90°, LIQUID TIGHT FITTING 2
11 BOLT, 1/2" X 1-3/4" GRD 8 ....................................................... 4 ........... OBTAIN LOCALLY
11A WASHER, FLAT, 1/2" ................................................................ 4 ........... OBTAIN LOCALLY
11B WASHER, LOCK, 1/2" .............................................................. 4 ........... OBTAIN LOCALLY
11C NUT, HEX 1/2" .......................................................................... 4 ........... OBTAIN LOCALLY
12 EE57757 LABEL, VINYL, DIAGRAM 1
13 EE56924 TRAY, TRANSFORMER 1
14 EE57351 TRANSFORMER, 600V, 3-PHASE, 75KVA 1
15 EE57536 CONDUIT, LIQUID TIGHT FLEXIBLE 1-1/2" ........................... 10 .......... 1PC = 1FT
16 EE57535 CABLE, 2 AWG SIM PULL THHN/90 BLACK .......................... 75 .......... 1PC = 1FT
17 EE22962 BRACKET, MTG. FOR CONDUIT, ALUMINUM 1
18 BOLT, M6 X 20 .......................................................................... 1 ........... OBTAIN LOCALLY
18A NUT, M6 .................................................................................... 2 ........... OBTAIN LOCALLY
19 EE57537 STRAIGHT, LIQUID TIGHT FITTING 2
