dca70SSJU4i 60 hz generator• operation manual — rev. #2 (04/09/14) — page 103
CaMLOCk assy. (OptiON)
no. part no. part name QtY. remarKs
1 CAMLOK1BKIT CAMLOK, 1 SET ....................................................................... 1 ........ INCLUDES ITEMS W/%
1 CAMLOK1BKITAL CAMLOK, 1 SET ALUMINUM .................................................. 1 ........ INCLUDES ITEMS W/#
2%# 0016906016 HEX HEAD BOLT 6
3%# EE6381 RECEPTACLE, FEMALE, BLUE, 4/0 1
4%# EE6378 RECEPTACLE, FEMALE, BLACK, 4/0 1
5%# EE6380 RECEPTACLE, FEMALE, RED, 4/0 1
6%# EE6379 RECEPTACLE, FEMALE, WHITE, 4/0 1
7%# EE6382 RECEPTACLE, FEMALE, GREEN, 4/0 1
8%# CL40WTCL125J SNAP BACK PLASTIC COVER 5
9% CAMPAN7085 PANEL, SINGLE CONDUCTOR CAMLOK 1
9# EE56978 PANEL, SINGLE CONDUCTOR CAMLOK, ALUMINUM 1
10 SCREW, 10-24 X 1" ................................................................. 20 ....... OBTAIN LOCALLY
11 CAP NUT, 10-24 ...................................................................... 20 ....... OBTAIN LOCALLY
12 SPACER, 1/2" DIA. ..................................................................AR ...... OBTAIN LOCALLY
13 STAR WASHER, 1/2" ................................................................ 5 ........ OBTAIN LOCALLY
14 BRASS NUT, 1/2-13 ................................................................. 5 ........ OBTAIN LOCALLY
