Accessory mounting dimensions – MTS Acumen Electrodynamic Test System Load Frame User Guide User Manual
Page 42

Accessory Mounting Dimensions
You can attach numerous testing accessories and fixtures to the load frame for specialized tests. The following
figures show the standard mounting holes in each style of load frame. Use these standard mounting holes
to mount your accessories. Do not drill or tap new holes that may weaken or otherwise compromise the
integrity of the load frame.
The following sections describe each style of load frame. Some dimensions are the same for all MTS Acumen
models, and are only listed once. Look for the section pertaining to your specific model for the appropriate
dimensions.
Note:Unless otherwise specified, the tolerance for all dimensions is ±0.254 mm (0.010 in).
MTS Acumen Accessory Overview
The following graphic shows the locations of the different mounting options.
MTS Acumen Accessory Overview
Dimension
Item
Actuator Fixture Mounting
A
42 MTS Acumen™ Electrodynamic Test System
Installation
