Page 31

Electrical connections must be made by qualified personnel and conform to local codes and regulations.
Local electrical codes supersede any information found here.
MTS Acumen 3
MTS Acumen 1
Electrical Requirements
200-240 VAC
100-120 VAC (200-240)
Voltage
50-60 Hz
50-60 Hz
Frequency
10 Amp
7 (4) Amp
Current
7
Single
Single
Phase
MTS Acumen Force Ratings
Note:
Specifications subject to change without notice.
Force Ratings
MTS Acumen 3
MTS Acumen 1
Specification
3000 N (670 lbf)
1250 N (280 lbf)
Dynamic force
8
2000 N (450 lbf)
850 N (190 lbf)
Static force
9
70 mm (2.76 in)
70 mm (2.76 in)
Actuator dynamic stroke
10
>100 Hz
>100 Hz
Dynamic performance
7
MTS Acumen 1 current rated at 100 VAC. MTS Acumen 3 current rated at 200 VAC.
8
Verifiable with MTS compression spring test. Performance may vary depending on test type, test setup,
frequency, specimen, environment, and other factors.
9
Verifiable with MTS compression spring test. Performance may vary depending on test type, test setup,
frequency, specimen, environment, and other factors.
10
+/- 35 mm
MTS Acumen™ Electrodynamic Test System 31
