Signal Pin
ESTOPA_OUT+ 14
No Contact 15
Note:If E-STOP_OUT is not used, pins 3 and 4 must be jumpered together.
Accelerometer (D9S)
Signal Pin
FB+ 1
FB- 2
No Contact 3
No Contact 4
No Contact 5
No Contact 6
No Contact 7
EX+ 8
EX- 9
Enclosure Switch (D9S)
Signal Pin
GUARD_VCC 1
GUARDA+ 2
GUARDA 3
GUARDB+ 4
GUARDB 5
No Contact 6
GUARD_GND 7
No Contact 8
No Contact 9
