MK-1600
PRODUCT SPECIFICATION
Blade
The MK-1600 uses a 16 or 18 inch diameter diamond blade.
Concrete Saw Usage
The MK-1600 is designed to cut various grades of concrete surfaces.
PRODUCT SPECIFICATIONS
The MK-1600 is a versatile gas powered Concrete Saw. Operated and used according to this manu-
al, the MK-1600
will provide years of dependable service.
General Description
The MK-1600 is engineered as a portable concrete saw powered by a Honda, Vanguard or Kohler
gas engine.The saw is capable of 6-5/8” depth of cut with an 18” blade.
Motor and Weight Specifications
Motor and Weight specifications for the MK-1600
are listed below.
Model
MK-1609H Standard MK-1613H Standard MK-1613S Standard MK-1613V Standard
Engine
Honda (Gas)
Honda (Gas)
Subaru (Gas)
Vanguard (Gas)
Power
GX240 Cyclone
GX390 Cyclone
EH41
V-Twin
Weight
210 lbs. (95 kgs)
223 lbs. (101 kgs)
223 lbs. (101 kgs)
233 lbs. (106 kgs)
Part #
157867
160832
160832-S
169948
General Specifications
Arbor Size
1” (25mm)
Blade Capacity
18” (45mm)
Blade RPM
2,700
Depth of Cut
6-5/8” (168mm)
L x W x H (inches) 42” x 25” x 39”
L x W x H (mm)
1067 x 635 x 991
Model
MK-1614K Standard MK-1613S Premium MK-1614K Premium MK-1613H Premium
Engine
Kohler (Gas)
Subaru (Gas)
Kohler (Gas)
Honda (Gas)
Power
CH440
EH41
CH440
GX390 Cyclone
Weight
223 lbs. (101 kgs)
233 lbs. (106 kgs)
233 lbs. (106 kg)
233 lbs. (106 kg)
Part #
157864-K
160772-S
168930
160772
MK-1600 Series Features
• One-piece box construction chassis made from 3/16” hot-rolled steel
• Powder-coated chassis resists peeling and corrosion
• Cast-aluminum hinged blade guard
• Stainless steel water distribution system supplies water to both sides of blade
• Blade guard mounts on both left- or right-hand side of saw and cuts within 2” of wall or curb
• 1” blade shaft supported by two heavy-duty, self-aligning pillow block bearings
• Depth control assembly engineered for smooth, controlled blade insertion
• Durable 8” x 2-1/4” non-slip rubber wheels with maintenance-free hubs & roller bearings
• Positive-locking depth control mechanism
• Premium Series saws include built-in depth gauge, tach/hour meter, and lifting bail
• One-year limited warranty
