(A)

Remove the Diamond Blade

and recheck vibration

(B)

Remove the Belt Guard

(C)

Remove the V-belts

(D)

Clean motor and

recheck vibration

Vibration

MK-5005S

TRoUBlESHooTING

(G)

Rod Cooling Channels and

recheck flow

(H)

Verify Water Pump suction is

clean and pump impeller is

turning. Pump Impeller is inside

water inlet

(I)

Verify Water Pump drive end is

in the operating position
