water Pump Preparation
(B)
Press the end of the Cooling
Transfer Tube onto the Water
Pump Discharge Fitting
(A)
Install Water Pump
Discharge Fitting
MK-5005S
aSSEMBlY
(D)
Install the Diamond Blade onto
the Blade Shaft
(E)
Verify the blade is seated on
the Blade Shaft and direction of
rotation is correct
(F)
Install Retaining Screw and
Outer Flange
(G)
Rotate Blade Wrench clockwise
to tighten
