PSL-25

SEAM-LOC 24

®

© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11

800.406.7387 (Corporate Office) • www.metalsales.us.com

ssr r

idge

d

eTail

SSR Ridge

Compression Plate

#12-14 x 1" SD N/W (see below)

#

1

/

4

-14 x

7

/

8

" Stitch XL (3 per panel)

Double Bead Tape Sealant

Seam-Loc 24 Metal Outside Closure

Double Bead Tape Sealant

Clip with (2) #

1

/

4

-14 x 1

1

/

2

" SD N/W

Seam-Loc 24 Panel

9"

1

1

/

2

"

3"

CL

Seam-Loc 24 Fastening Pattern

D. B. T. S.

Metal Outside Closure

#12-14 x 1" SD N/W

2

6

5

4

1

3
