seam-loC 24
®
s
CUlPTUred
g
UTTer
d
eTail
CAUTION
In locations where heavy
rainfall or severe ice and
snow may occur, Metal
Sales' standard gutters may
not be suitable for use.
1
/
4
:12 SLOPE
MINIMUM
#
1
/
4
-14 x
7
/
8
" Stitch XL (2 per panel)
Eave Plate
Gutter Drip
SSR Sculptured Gutter
#12-14 x 1
1
/
4
" SD XL (2 per support)
SSR Gutter Support (every other panel)
1
/
8
x
3
/
16
" Pop Rivet (every support)
#12-14 x 1
1
/
4
" SD XL (see below)
#12-14 x 1" SD N/W (1'-0" o.c.)
Seam-Loc 24 Panel
Seam-Loc 24 Metal Inside Closure
Double Bead Tape Sealant
e
ndlaP
d
eTail
1
/
4
:12 SLOPE
MINIMUM
Seam-Loc 24 Panel (factory notched)
Endlap Pad
#12-14 x 1
1
/
2
" SD XL (see below)
Compression Plate
6" for 3" Endlap
9" for 6" Endlap
3" or 6"*
Clip with (2) #
1
/
4
-14 x 1
1
/
2
" SD N/W
Seam-Loc 24 Panel (pre-punched)
1
1
/
2
"
Tube Sealant
A-A
A
A
Seam-Loc 24 Fastening Pattern
D. B. T. S.
#12-14 x 1" SD N/W
Metal
Inside
Closure
#12-14 x 1
1
/
2
" SD XL
2
6
5
4
1
3
Seam-Loc 24 Fastening Pattern
#12-14 x 1
1
/
2
" SD XL
2
6
5
4
1
3
* 3" Endlap Available at Jacksonville Branch Only.
